W220 Rail Clip
The W220 rail clip is engineered for ultra-heavy crane rails and industrial tracks where extreme loads and constant vibration demand the highest performance. Its welded base and self-locking top secure rails with precision, ensuring stable, long-term alignment in container terminals, steel mills, and heavy-duty crane systems.
Capable of withstanding a horizontal side load of 300 kN (30.6 tonnes) and offering 21 mm lateral adjustment, the W220 combines robust strength with a low-profile design for cranes equipped with guide rollers or tracks with limited vertical clearance.
Features of W220 Rail Clip
- Extreme Load Holding
Designed for the heavy crane rails, the W220 maintains consistent clamping even under continuous lateral forces and shock. - Self-Locking Forged Body
The M20 bolt locks the two main parts securely, preventing loosening under high-vibration environments. - Vibration-Damping Rubber Block
The vulcanized insert cushions the rail, reducing noise, wear, and metal fatigue while maintaining precise clamping pressure. - Welded Base for Long-Term Stability
Once welded, the clip forms a permanent, vibration-resistant connection, eliminating the need for underside access or frequent maintenance. - Adaptable to Diverse Rails
Compatible with a broad range of crane and industrial rails. Contact Glory Track for rails not listed in the table to find the optimal solution.
Technical Specifications & Materials
Specifications:
- Model: W220/21/43
- Max Side Load: 300 kN (30.6 t)
- Horizontal Adjustment: 21 mm
Dimensions (mm):
- X: 43
- Y (Full Nut): 50
- Y (Thin Nut): 45
- Z: 33
- Weight: 2.5 kg
- With Rail Pad (S): 14 mm plan
- Without Rail Pad (H): 21 mm plan
Material:
- Material (standard) Weldable grade steel (Q235 or custom materials)
- Vulcanized rubber block for controlled force
- Surface treatment: Hot-dip galvanizing for top cover and bolts; welded base normally left bare for welding
Installation of W220 Rail Clip
- Step 1 – Weld Base
Weld the clip base to the support beam using 5 mm fillet welds, leaving the side parallel to the rail unwelded. Use low-hydrogen electrodes (AWS E7018 / E7028) for high-strength bonding. - Step 2 – Position Clip
Place the forged clip so the rubber block presses firmly against the rail flange. - Step 3 – Insert and Tighten Bolts
Insert the M20 bolt and washer, tighten lightly until the clip contacts the rail securely. - Step 4 – Final Torque
Tap the clip for precise alignment, then torque the bolt to 350 Nm to lock the assembly firmly.
For detailed welding diagrams or torque charts, contact Glory Track technical support.
Rail Compatibility of W220 Rail Clip
The W220 rail clip works with heavy-duty crane and industrial rails, accommodating various rail pad thicknesses and support beam widths. For rails not listed in the table, consult Glory Track engineers to determine the optimal configuration.
| Rail Type | F (mm) | C (mm) | A (mm) | Rail Weight (kg/m) | Clip Reference for Rail with Pad | Clip Reference for Rail without Pad |
|---|---|---|---|---|---|---|
| QU 80 | 130 | 80 | 130 | 63.69 | W220/21/43 (S) | W220/21/43 (H) |
| QU 100 | 150 | 100 | 150 | 89 | W220/21/43 (S) | W220/21/43 (H) |
| QU 120 | 170 | 120 | 170 | 118.5 | W220/21/43 (S) | W220/21/43 (H) |
| A 100 | 200 | 100 | 95 | 74.3 | W220/21/43 (S) | W220/21/43 (H) |
| A 120 | 220 | 120 | 105 | 100 | W220/21/43 (S) | W220/21/43 (H) |
| A 150 | 220 | 150 | 150 | 150.3 | W220/21/43 (S) | W220/21/43 (H) |
| ISCR 100 | 150 | 102 | 150 | 89 | W220/21/43 (S) | W220/21/43 (H) |
| ISCR 120 | 170 | 120 | 170 | 118.5 | W220/21/43 (S) | W220/21/43 (H) |
| ISCR 140 | 170 | 140 | 170 | 146 | W220/21/43 (S) | W220/21/43 (H) |
| GCR 183 | 280 | 75 | 120 | 183.06 | W220/21/43 (S) | W220/21/43 (H) |
| CR 73 | 140 | 100 | 135 | 73.3 | W220/21/43 (S) | W220/21/43 (H) |
| CR 100 | 155 | 120 | 150 | 100.2 | W220/21/43 (S) | W220/21/43 (H) |
| 73 kg AS | 146 | 70 | 157 | 73.6 | W220/21/43 (S) | W220/21/43 (H) |
| 86 kg AS | 165 | 102 | 102 | 85.5 | W220/21/43 (S) | W220/21/43 (H) |
| MRS 67 (135CR) | 132 | 79 | 146 | 67 | W220/21/43 (S) | W220/21/43 (H) |
| MRS 86 | 165 | 102 | 102 | 85.5 | W220/21/43 (S) | W220/21/43 (H) |
| MRS 87 A (PRI85R) | 152 | 102 | 152 | 86.8 | W220/21/43 (S) | W220/21/43 (H) |
| MRS 125 | 180 | 120 | 180 | 125 | W220/21/43 (S) | W220/21/43 (H) |
| MRS 221 | 220 | 220 | 160 | 221.4 | W220/21/43 (S) | W220/21/43 (H) |
| 68 kg AS | 152 | 73 | 186 | 67.6 | W220/21/43 (S) | W220/21/43 (H) |
| 89 kg CR | 178 | 102 | 114 | 89.8 | W220/21/43 (S) | W220/21/43 (H) |
