A45 Crane Rail
A45 Crane Rail, named for its 45 mm head width under DIN 536 P1:1991 standards (also referred to as Rail A45 DIN536 or Rail Type A45), is a light-duty rail hot-rolled from Manganese steel to balance strength and toughness. With a low-height, wide-base design and thick web, it resists moderate wheel pressures and impacts. Weighing 22.1 kg/m, the A45 rail weight ensures reliable performance for light-duty crane tracks. Its precise A45 rail dimensions provide smooth operation for small gantry cranes in workshops, overhead hoists on assembly lines, and portable maintenance trolleys in warehouses, making it ideal for applications where easy installation, cost-effectiveness, and consistent operation under intermittent loads are crucial.
Specifications of A45 Rail
| Height: 55 mm | Base Width: 125 mm |
| Head Width: 45 mm | Web Thickness: 24 mm |
| Length: 6m-12m | Material: 50Mn |
| Weight: 22.1 kg/m | Standard: DIN536 P1:1991 |
If you have special requirements for length or higher strength materials, please contact us for special custom production.
A45 Crane Rail Steel Grade & Material
The A45 crane rail is manufactured from 50Mn steel, chosen for its excellent toughness, wear resistance, and weldability. This high-quality material ensures reliable performance under moderate wheel loads, making it ideal for light-duty crane tracks in workshops, assembly lines, and maintenance areas. With 50Mn steel, the A45 rail maintains long-term durability and consistent operation in indoor industrial applications.
Applications of A45 Crane Rail
Indoor Handling
Ideal for light indoor cranes, small factory hoists, and portable trolleys. Its lightweight and balanced A45 rail profile support smooth and safe movement.
Assembly Lines
Used in production lines for small-to-medium equipment handling. Reliable support reduces wear and ensures consistent crane operation.
Maintenance Areas
Suited for low-load crane systems in maintenance shops. Easy installation and durable design improve workflow efficiency.
Processing Options for A45 Crane Rail
The A45 rail track can be processed in multiple ways to match different project requirements, ensuring easy installation, reliable joints, and long-lasting performance.
Our Services Include:
- Beveled Cutting: Rail ends cut at an angle for smooth welding joints.
- L-Shaped Cutting: Special joint design for stronger mechanical connection.
- Protective Coating: Anti-rust oil, paint, or zinc for corrosion resistance.
- Short Rail Fabrication: Rail A45 can be manufactured in short rail to meet the specific track requirements of gantry cranes and trolley systems in ports.
A45 Crane Rail Export and Container Loading
Glory Track has rich experience in exporting A45 rail worldwide, including Africa, South America, Southeast Asia, and the Middle East. Rails are bundled with steel straps, fixed by wooden blocks, and optionally covered with waterproof tarpaulin to ensure safe sea transport. Accessories such as rail clamps and fishplates are packed in fumigation-free wooden boxes for secure delivery.
By following strict export standards and careful container loading, we guarantee every rail A45 DIN536 shipment arrives on time and in perfect condition. Our team also offers flexible loading plans, supporting mixed orders with different rail sizes and components to optimize shipping costs.
FAQ—Customer Concerns for A45 Crane Rail
What is the maximum length available for A45 rail?
→ Standard lengths are 6–12 meters, but Glory Track can supply custom lengths, including short rails tailored for port cranes or workshop layouts.
How is A45 rail typically fixed to the ground?
→ A45 crane rail can be installed using rail clamps, bolts, or by welding, depending on the crane type and ground structure. Our team provides guidance and accessories for secure installation.
What types of equipment is A45 crane rail suitable for?
Can A45 crane rail be customized for tight curvature or special layouts?
→Yes. Our in-house bending and cutting capabilities allow A45 rails to be shaped for tight curves, gantry cranes, or non-standard track layouts, ensuring precise alignment and smooth crane operation.
A45 Crane Rail for Sale
At Glory Track, we provide more than just A45 crane rail. Our customers benefit from 15+ years of experience in manufacturing and supplying light-duty rails, backed by ISO 9001-certified quality and a proven track record in international projects.
We ensure reliable delivery, flexible order quantities, and responsive technical support. By partnering with us, clients gain tailored solutions, consistent product quality, and the assurance of working with a supplier committed to long-term reliability and service excellence.
Rail Components You May Need
Looking for a complete rail solution? We also supply compatible components and systems
Rail Fasteners
Ensure rail stability and secure installation with durable spikes, bolts, and clips.
Fish Plates
Connect rail sections firmly to maintain track alignment and structural integrity.
Steel sloeplates
Distribute loads evenly and protect the base structure while enhancing insulation.
Rail Pads
Absorb vibration and noise to protect the track and extend its service life.
Request a Quote for A45 Rails
Ideal for light-duty tracks or small transport systems. To quote accurately, please tell us:
- Where will the rails be used (type of equipment or site)?
- Any processing needed—cutting, bending, or coating?
- Specific load or dimensional requirements?
